FC-CO-5000

FC-CO-5000

Manufacturer:: PROSENSE

PROSENSE FC-CO-5000 High-Range Fuel Cell Carbon Monoxide Sensor

Specifications

Product Introduction

The Model FC-CO-5000 Carbon Monoxide sensor, known for its exceptional durability, operates on oxidized, generating an electrical signal directly proportional to the CO concentration. By calibrating the sensor with a known CO concentration, its output current can be used for accurate quantitative measurement of CO levels. Renowned for its long service life, high resistance to interference, and compact design, the FC-CO-5000 is an excellent choice for size-sensitive applications such as portable CO detectors, residential CO alarms, and multi-sensor fire detectors. Calibration data is embedded in a barcode printed on the sensor, allowing users to bypass expensive gas calibration processes and enabling individual sensor tracking. With no consumable components, the FC-CO-5000 offers outstanding longevity and ensures a maintenance-free operation, making it a reliable and cost-effective solution for CO detection.

Features

  • Zero power consumption
  • Fast Response
  • High Accuracy
  • Anti-interference
  • Anti-poisoning
  • Wide Temperature Range
  • Long Service Life
  • Excellent Stability and Repeatability
  • UL Recognized, FTAM2 Certified
  • Fulfill Requirements of GB 15322, UL 2034, EN 50291 and UL 2075 application

Applications

  • Residential CO Detector
  • Commercial and Industrial CO Detector
  • Portable Generator CO Detection
  • Energy Storage System CO Detection

Specifications Table

Parameter Value
Model Number FC-CO-5000
Principle Micro fuel cell
Detection range 0-5000 ppm
Overload 10000 ppm
Sensitivity 1.5±1(nA/ppm)
Response time ＜60 Seconds
Repeatability 3%
Operating temperature -40℃～70℃
Operating pressure 1atm±10％
Operating humidity 10％－90％RH(non-condensation)
Reading in 1000 ppm Alcohol ＜10 ppm

To learn more, please download the PDF.
